China 50 100 200 300 Micron Stainless Steel Printing Wire Mesh Manufacturer and Supplier

50 100 200 300 Micron Stainless Steel Printing Wire Mesh

Short Description:

High-precision 50/100/200/300 micron stainless steel printing wire mesh, 304/316L plain weave, low elongation, high tension, solvent & heat resistant. Custom rolls & sheets for PCB, solar cell, conductive paste screen printing. ISO certified factory direct supply.

Material: SUS304, 316L, 310S

Weave Type: Plain weave (industry standard for screen printing, uniform ink transfer, minimal deformation)

Aperture Precision: ±2μm micron tolerance

Wire Diameter: Custom matched to 50/100/200/300 micron

Standard roll width: 1m, 1.2m, 1.5m, 1.8m, 2m; custom slitting widths available

Standard roll length: 30m/50m per roll

Send email to us Download as PDF

Product Detail

Product Tags

Using a complete scientific top quality management program, great high-quality and fantastic religion, we win great track record and occupied this area for Hot-selling China Ultra Fine 50 100 200 300 Micron Stainless Steel Printing Wire Mesh, To significantly improve our assistance quality, our company imports a large number of international advanced devices. Welcome clients from your home and abroad to simply call and inquire!
Using a complete scientific top quality management program, great high-quality and fantastic religion, we win great track record and occupied this area for China Stainless Steel, Wire Mesh, we sincerely hope to establish a good and long-term business relationship with your esteemed company through this opportunity, based on equality, mutual benefit and win-win business from now to the future. “Your satisfaction is our happiness”.

Stainless Steel Wire Mesh

Stainless Steel Wire Mesh can be divided into stainless steel plain-woven wire mesh, stainless steel twill woven wire mesh, stainless steel three Heddie wire mesh, stainless steel three Heddie wire mesh.

Stainless steel wire mesh products Net surface:

clean, smooth, small magnetic

Wire Material:

Carbon Steel: Low,Hiqh,Oil Tempered
Stainless Steel: Non-Magnetic Types 304,304L,309310,316,316L,317,321,330,347,2205,2207,Magnetic Types 410,430 ect.
Special materials: Copper, Brass, Bronze, Phosphor Bronze,red copper,Aluminum,Nickel200,Nickel201, Nichrome,TA1/TA2,Titanium ect.

Packing:

Water-Proof ,Plastic Paper, Wooden Case ,Pallet

Stainless Steel Wire Mesh Product Features:

Heat, acid, corrosion resistance, wear resistance. Surface smooth, clean, non-toxic, health, environmental protection.tainless steel wire mesh products uses:

Chemicals: acid solution filtration, chemical experiments, chemical particulate filter, gas filter corrosive, caustic dust filtration

Oil: oil purification, oil mud filtration, separation of impurities, etc.

Medicine: Chinese medicine decoction filtration, the solid particulate filtration, purification, and other drugs

Electronics: Circuit board framework, electronic components, battery acid, radiation module

Printing: Ink filtration, carbon filtration, purification, and other toners

Equipment: vibrating screen

Basic Info

Woven Type: Plain Weave and Twill Weave

Mesh: 1-635 mesh, To accurately

Wire Dia.: 0.022 mm – 3.5 mm, small deviation

Width: 190mm, 915mm, 1000mm, 1245mm to 1550mm

Length: 30m, 30.5m or cut to length minimum 2m

Hole shape: Square Hole

Wire Material: stainless steel wire

Mesh Surface: clean, smooth, small magnetic.

Packing: Water-Proof, Plastic Paper, Wooden Case, Pallet

Min.Order Quantity: 30 SQM

Delivery Detail: 3-10 days

Sample: Free Charge

Common specifications of woven mesh

Mesh	Wire Dia. (inches)	Wire Dia. (mm)	Opening(inches)	Opening(mm)
1	0.135	3.5	0.865	21.97
1	0.08	2	0.92	23.36
1	0.063	1.6	0.937	23.8
2	0.12	3	0.38	9.65
2	0.08	2	0.42	10.66
2	0.047	1.2	0.453	11.5
3	0.08	2	0.253	6.42
3	0.047	1.2	0.286	7.26
4	0.12	3	0.13	3.3
4	0.063	1.6	0.187	4.75
4	0.028	0.71	0.222	5.62
5	0.08	2	0.12	3.04
5	0.023	0.58	0.177	4.49
6	0.063	1.6	0.104	2.64
6	0.035	0.9	0.132	3.35
8	0.063	1.6	0.062	1.57
8	0.035	0.9	0.09	2.28
8	0.017	0.43	0.108	2.74
10	0.047	1	0.053	1.34
10	0.02	0.5	0.08	2.03
12	0.041	1	0.042	1.06
12	0.028	0.7	0.055	1.39
12	0.013	0.33	0.07	1.77
14	0.032	0.8	0.039	1.52
14	0.02	0.5	0.051	1.3
16	0.032	0.8	0.031	0.78
16	0.023	0.58	0.04	1.01
16	0.009	0.23	0.054	1.37
18	0.02	0.5	0.036	0.91
18	0.009	0.23	0.047	1.19
20	0.023	0.58	0.027	0.68
20	0.018	0.45	0.032	0.81
20	0.009	0.23	0.041	1.04
24	0.014	0.35	0.028	0.71
30	0.013	0.33	0.02	0.5
30	0.0065	0.16	0.027	0.68
35	0.012	0.3	0.017	0.43
35	0.01	0.25	0.019	0.48
40	0.014	0.35	0.011	0.28
40	0.01	0.25	0.015	0.38
50	0.009	0.23	0.011	0.28
50	0.008	0.20`	0.012	0.3
60	0.0075	0.19	0.009	0.22
60	0.0059	0.15	0.011	0.28
70	0.0065	0.17	0.008	0.2
80	0.007	0.18	0.006	0.15
80	0.0047	0.12	0.0088	0.22
90	0.0055	0.14	0.006	0.15
100	0.0045	0.11	0.006	0.15
120	0.004	0.1	0.0043	0.11
120	0.0037	0.09	0.005	0.12
130	0.0034	0.0086	0.0043	0.11
150	0.0026	0.066	0.0041	0.1
165	0.0019	0.048	0.0041	0.1
180	0.0023	0.058	0.0032	0.08
180	0.002	0.05	0.0035	0.09
200	0.002	0.05	0.003	0.076
200	0.0016	0.04	0.0035	0.089
220	0.0019	0.048	0.0026	0.066
230	0.0014	0.035	0.0028	0.071
250	0.0016	0.04	0.0024	0.061
270	0.0014	0.04	0.0022	0.055
300	0.0012	0.03	0.0021	0.053
325	0.0014	0.04	0.0017	0.043
325	0.0011	0.028	0.002	0.05
400	0.001	0.025	0.0015	0.038
500	0.001	0.025	0.0011	0.028
635	0.0009	0.022	0.0006	0.015
