Project Requirements

Based on the customer’s working conditions, the main requirements included:

After reviewing the application requirements, DXR recommended 304 Stainless Steel 24×110 Dutch Weave Wire Mesh as the filtration solution.

Recommended Solution

304 Stainless Steel 24×110 Dutch Weave Wire Mesh

The selected wire cloth was manufactured using 304 stainless steel wire with:

• Mesh Count: 24 × 110

• Warp Wire Diameter: 0.355 mm

• Weft Wire Diameter: 0.25 mm

• Nominal Opening: Approximately 105 μm

• Weave Type: Dutch Weave

Unlike standard square woven mesh, Dutch weave wire mesh uses different wire diameters in the warp and weft directions.

This structure creates a filtration-focused surface with controlled openings while maintaining good mechanical stability.

For industrial filtration applications, Dutch weave mesh is commonly selected when both filtration accuracy and durability are important.

Manufacturing Process

To meet the customer’s requirements, DXR supplied the mesh with controlled production procedures:

1. Material Selection

304 stainless steel wire was selected because it provides:

• Good corrosion resistance

• Stable mechanical properties

• Long service life in general industrial environments

2. Precision Weaving

The 24×110 Dutch weave structure was produced according to the required wire diameter combination.

The weaving process ensured:

• Uniform mesh structure

• Consistent opening distribution

• Stable filtration performance

3. Quality Inspection

Before shipment, the wire cloth was inspected for:

• Mesh count

• Wire diameter

• Aperture size

• Surface condition

• Overall weaving quality

Application Process

The supplied wire mesh was further fabricated into industrial filter components.

The final filtration components were installed in an oil filtration system to remove suspended particles and contaminants from industrial fluids.

The 105 μm opening specification helped provide controlled particle separation while the stainless steel woven structure supported continuous operation.

Application Results

After implementation, the customer achieved:

Stable Filtration Performance

The Dutch weave structure provided a more controlled filtration surface compared with conventional screening mesh.

Improved Filter Durability

The stronger wire structure helped maintain mesh stability during repeated operation.

Better Equipment Compatibility

The woven cloth could be customized into filter discs, screens and other filtration components according to equipment requirements.

Reduced Maintenance Frequency

The durable stainless steel construction helped extend service intervals and improve overall filtration reliability.

Why Choose Dutch Weave Wire Mesh for Oil Filtration?

Oil filtration systems often require a combination of:

• Accurate particle retention

• Mechanical strength

• Corrosion resistance

• Long-term operational stability

Dutch weave wire mesh provides advantages through its unique woven structure.

Compared with ordinary square mesh:

Related Products

For different filtration requirements, DXR also supplies:

316L Stainless Steel Dutch Weave Wire Mesh

Recommended for:

• Chemical filtration

• Pharmaceutical applications

• Corrosive environments

Reverse Dutch Weave Wire Mesh

Recommended for:

• High-pressure filtration

• Polymer filtration

• Extrusion applications

Stainless Steel Filter Disc

Recommended for:

• Oil filtration equipment

• Hydraulic systems

• Process filtration

Stainless Steel Filter Tube

Recommended for:

• Continuous liquid filtration

• Pipeline filtration systems

Industries Using Similar Filtration Solutions

304 Dutch weave wire mesh solutions are widely considered for applications including:

Oil and Gas Filtration

Used for separating solid particles from industrial oils and process fluids.

Chemical Processing

Used where stainless steel filtration media is required for compatible chemical environments.

Plastic Extrusion

Fine filtration mesh is used in extrusion processes requiring contamination removal.

Industrial Equipment

Used as filter screens, discs and customized filtration components.

DXR Custom Filtration Support

Every filtration system has different operating conditions.

Mesh selection should consider:

• Required filtration rating

• Fluid characteristics

• Temperature

• Pressure

• Filter structure

• Service environment

DXR provides customized stainless steel Dutch weave wire mesh solutions according to customer drawings, specifications and application requirements.

Request a Custom Dutch Weave Wire Mesh Solution

Need 304 stainless steel 24×110 Dutch weave wire mesh for your filtration application?

Send us your:

• Mesh specification

• Material requirement

• Filter design

• Quantity

• Application details

Our technical team can help recommend a suitable wire mesh solution.
