Aluminium Wire Mesh
Aluminium Wire Mesh
Aluminum Wire Mesh is lightweight; in fact, a good rule of thumb is that, when compared to its stainless steel counterpart, aluminum mesh is approximately 1/3rd the weight of stainless.
Aluminum is largely considered the most popular non-ferrous metal in the world, and as such, aluminum alloys are commonly used in the wire mesh industry. Aluminum alloys are composed primarily of aluminum, and also contain other elements like copper, magnesium, manganese, or silicon.
Aluminum wire mesh is also corrosion resistant in most normal environments but will corrode quickly in the presence of alkaline solutions and hydrochloric and hydrofluoric acids. With an estimated melting point of 1218°F, aluminum has many benefits, including a relatively low cost compared to other meshes. Aluminum woven wire mesh is a popular choice for a wide array of industries including aerospace and automotive, as well as marine and electrical conductivity applications.
Raw Material and Alloy Options
We select multiple food-grade & industrial aluminum raw materials to match different working environments, avoiding material mismatch failures for clients:
1050 / 1060 pure aluminum: Superior electrical conductivity, ideal for electromagnetic shielding, ventilation screens, low-cost general filtration
5052 aluminum-magnesium alloy: Enhanced salt spray resistance, better tensile strength, suitable for coastal, marine outdoor applications
All aluminum wires feature stable melting point at 1218°F, good ductility for secondary processing like cutting, bending, rolling and frame forming.
|
Mesh |
Wire Dia.(inches) |
Wire Dia.(mm) |
Openging(inches) |
Openging(mm) |
|
1 |
0.135 |
3.5 |
0.865 |
21.97 |
|
1 |
0.08 |
2 |
0.92 |
23.36 |
|
1 |
0.063 |
1.6 |
0.937 |
23.8 |
|
2 |
0.12 |
3 |
0.38 |
9.65 |
|
2 |
0.08 |
2 |
0.42 |
10.66 |
|
2 |
0.047 |
1.2 |
0.453 |
11.5 |
|
3 |
0.08 |
2 |
0.253 |
6.42 |
|
3 |
0.047 |
1.2 |
0.286 |
7.26 |
|
4 |
0.12 |
3 |
0.13 |
3.3 |
|
4 |
0.063 |
1.6 |
0.187 |
4.75 |
|
4 |
0.028 |
0.71 |
0.222 |
5.62 |
|
5 |
0.08 |
2 |
0.12 |
3.04 |
|
5 |
0.023 |
0.58 |
0.177 |
4.49 |
|
6 |
0.063 |
1.6 |
0.104 |
2.64 |
|
6 |
0.035 |
0.9 |
0.132 |
3.35 |
|
8 |
0.063 |
1.6 |
0.062 |
1.57 |
|
8 |
0.035 |
0.9 |
0.09 |
2.28 |
|
8 |
0.017 |
0.43 |
0.108 |
2.74 |
|
10 |
0.047 |
1 |
0.053 |
1.34 |
|
10 |
0.02 |
0.5 |
0.08 |
2.03 |
|
12 |
0.041 |
1 |
0.042 |
1.06 |
|
12 |
0.028 |
0.7 |
0.055 |
1.39 |
|
12 |
0.013 |
0.33 |
0.07 |
1.77 |
|
14 |
0.032 |
0.8 |
0.039 |
1.52 |
|
14 |
0.02 |
0.5 |
0.051 |
1.3 |
|
16 |
0.032 |
0.8 |
0.031 |
0.78 |
|
16 |
0.023 |
0.58 |
0.04 |
1.01 |
|
16 |
0.009 |
0.23 |
0.054 |
1.37 |
|
18 |
0.02 |
0.5 |
0.036 |
0.91 |
|
18 |
0.009 |
0.23 |
0.047 |
1.19 |
|
20 |
0.023 |
0.58 |
0.027 |
0.68 |
|
20 |
0.018 |
0.45 |
0.032 |
0.81 |
|
20 |
0.009 |
0.23 |
0.041 |
1.04 |
|
24 |
0.014 |
0.35 |
0.028 |
0.71 |
|
30 |
0.013 |
0.33 |
0.02 |
0.5 |
|
30 |
0.0065 |
0.16 |
0.027 |
0.68 |
|
35 |
0.012 |
0.3 |
0.017 |
0.43 |
|
35 |
0.01 |
0.25 |
0.019 |
0.48 |
|
40 |
0.014 |
0.35 |
0.011 |
0.28 |
|
40 |
0.01 |
0.25 |
0.015 |
0.38 |
|
50 |
0.009 |
0.23 |
0.011 |
0.28 |
|
50 |
0.008 |
0.20` |
0.012 |
0.3 |
|
60 |
0.0075 |
0.19 |
0.009 |
0.22 |
|
60 |
0.0059 |
0.15 |
0.011 |
0.28 |
|
70 |
0.0065 |
0.17 |
0.008 |
0.2 |
|
80 |
0.007 |
0.18 |
0.006 |
0.15 |
|
80 |
0.0047 |
0.12 |
0.0088 |
0.22 |
|
90 |
0.0055 |
0.14 |
0.006 |
0.15 |
|
100 |
0.0045 |
0.11 |
0.006 |
0.15 |
|
120 |
0.004 |
0.1 |
0.0043 |
0.11 |
|
120 |
0.0037 |
0.09 |
0.005 |
0.12 |
|
130 |
0.0034 |
0.0086 |
0.0043 |
0.11 |
|
150 |
0.0026 |
0.066 |
0.0041 |
0.1 |
|
165 |
0.0019 |
0.048 |
0.0041 |
0.1 |
|
180 |
0.0023 |
0.058 |
0.0032 |
0.08 |
|
180 |
0.002 |
0.05 |
0.0035 |
0.09 |
|
200 |
0.002 |
0.05 |
0.003 |
0.076 |
|
200 |
0.0016 |
0.04 |
0.0035 |
0.089 |
Core Product Advantages
Ultra-light weight: Cut transportation, installation and hoisting cost by over 60% vs stainless steel mesh; easy manual laying without heavy equipment
Natural atmospheric corrosion resistance: No rust under normal outdoor air, rain and neutral humidity; long service life for outdoor facilities
Excellent electrical conductivity: High conductivity aluminum base enables reliable EMI shielding for electronic cabinets, communication equipment
Easy processing & customizable: Support arbitrary length cutting, panel stamping, deep drawing, welding assembly; match OEM filter disc, ventilation screen, decorative mesh demands
Economic cost: Lower raw material price than nickel, titanium and stainless steel alloys, ideal for large-volume engineering procurement
Recyclable & eco-friendly: 100% recyclable aluminum material, meets global environmental protection standards for construction and industrial manufacturing
