China Wire Mesh Screen Filter Woven Wire Cloth
China Industrial Woven Wire Mesh Screen Filter Cloth
Are you troubled by unstable filtration accuracy, short service life, or poor corrosion resistance of your current filter media? Our woven wire cloth, professionally manufactured at DXR’s Anping factory, delivers consistent precision separation for liquid, gas and solid particle screening across global industrial sectors.
As a Chinese wire mesh manufacturer with over 30 years of focused production, we engineer stainless steel wire mesh screen filter cloth with strict ISO 9001 quality control. Unlike generic thin metal mesh, our loom-woven wire cloth features uniform aperture, high tensile strength and wide temperature adaptability, solving long-term operation pain points for chemical, food, new energy, petrochemical and environmental treatment factories.
Characteristics of stainless steel wire mesh
Good corrosion resistance: Stainless steel wire mesh is made of stainless steel, which has good corrosion resistance and can be used in harsh environments such as humidity and acid and alkali for a long time.
High strength: The stainless steel wire mesh has been specially processed to have high strength and wear resistance, and is not easy to deform and break.
Smooth and flat: The surface of the stainless steel wire mesh is polished, smooth and flat, not easy to adhere to dust and sundries, easy to clean and maintain.
Good air permeability: The stainless steel wire mesh has uniform pore size and good air permeability, suitable for applications such as filtration, screening and ventilation.
Good fireproof performance: stainless steel wire mesh has good fireproof performance, it is not easy to burn, and it will go out when it encounters fire.
Long life: Due to the corrosion resistance and high strength of stainless steel materials, stainless steel wire mesh has a long service life, which is economical and practical.
Available Material & Weave Types
1. Raw Material Options
- Stainless Steel Series: SUS304, SUS304L, SUS316, SUS316L, 904L, 310S, 430
- Special Alloy Mesh: Copper wire mesh, nickel mesh, titanium mesh, Monel, Inconel alloy mesh
- Low Carbon Steel: Black annealed wire cloth for plastic melt filtration
2. Four Main Weave Structures
- Plain Weave: Balanced open area, general screening & coarse filtration, widely used in food grain ventilation
- Twill Weave: Denser structure, higher strength, medium-precision liquid filtration
- Plain Dutch Weave: Small micron aperture, ideal for oil, chemical fine particle separation
- Twill Dutch Weave: Ultra-fine filter cloth, 200–635 mesh for lithium battery powder sorting, pharmaceutical filtration
Wide Industrial Application Scenarios
New Energy Lithium Battery Industry
300/325 mesh twill dutch woven wire cloth for ultrasonic vibrating screen, sorting ternary NCM, LFP cathode and anode powder, ensuring uniform particle size to boost battery cycle life and safety.
Chemical & Petrochemical Filtration
Dutch weave stainless steel mesh screen for oil impurity removal, liquid solid-liquid separation, chemical raw material filtration, resisting acid and organic solvent corrosion.
Food & Beverage Processing
Food-grade 304 woven wire cloth for syrup filtering, grain warehouse ventilation perforated mesh matching, spice powder screening, fully compliant with food contact safety standards.
Environmental & Water Treatment
Copper woven mesh for EMI shielding; stainless filter discs for wastewater impurity interception, sewage treatment fine filtration elements.
Pharmaceutical & Laboratory Screening
High-precision 200–400 mesh wire cloth for medicine powder grading, standard test sieve supporting raw material particle detection.
Fireproof & High-Temperature Textile Reinforcement
310S stainless steel woven mesh as inner reinforcement of fire-resistant fabric, improving tensile strength and heat insulation performance of fire curtains and welding protective blankets.
Frequently Asked Questions
A: Yes. We process woven wire cloth into filter discs, cylindrical filter tubes, basket strainers, rectangular filter panels and other finished filter elements according to your drawings. OEM custom sizes and shapes are fully supported.
A: Standard stock specifications ship within 3–7 working days; customized weaving or deep processing orders take 7–15 days based on order quantity.
A: Absolutely. Stainless steel woven mesh features smooth surface, easy to clean by ultrasonic cleaning or high-pressure water flushing, no deformation after repeated cleaning, much longer service life than disposable filter paper.
A: We provide free small-size mesh samples; clients only cover the international express freight cost.
